3" * 3" Squared Rainwater Downpipe Roll Forming Machine For Water Pipe, Rain Gutter

Place of Origin : China

Brand Name : TECHWELL

Certification : CE

Model Number : TW-DP100

MOQ : 1 Set

Price : Contact Us

Packaging Details : Standard packing

Delivery Time : 70-80 working days

Payment Terms : 40% T/T in advance, 60% T/T before shipment

Supply Ability : 20 sets

Material Spec : PPGI, Aluminum

Thickness of Coil Sheet : 0.4-0.6mm

Forming Motor Power : 7.5KW

Forming Speed : 0-15m/min (excluding cutting time)

Roller Material : High grade 45#, polished and coated with 0.05mm Chrome Surface.

Material of Axis : High grade 45# steel

Contact Now

3" * 3" Squared Rainwater Downpipe Roll Forming Machine For Water Pipe, Rain Gutter

Main Specifications

  • Main motor power: 7.5Kw
  • Number of forming station: About 20
  • Forming speed of downpipe roll forming machine: 6-12m/min
  • Voltage: 380 V, 3 Phase 50Hz ( or depend on customer’s requirement )
  • Dimension of machine: About 12000mm*1100mm*1200mm
  • Machine wight: about 12 Ton
  • Material of Axis: High grade 45# steel
  • Diameter of Axis: φ75mm
  • Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.
  • Materical of Machine Frame: A3 Steel, thickness 18mm
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand

Reference Rainspout Drawing

3" * 3" Squared Rainwater Downpipe Roll Forming Machine For Water Pipe, Rain Gutter

3" * 3" Squared Rainwater Downpipe Roll Forming Machine For Water Pipe, Rain Gutter

3" * 3" Squared Rainwater Downpipe Roll Forming Machine For Water Pipe, Rain Gutter

Main Components

  • Decoiler ---------------------------------------------- 1 Unit
  • Feeding guide --------------------------------------- 1 Unit
  • main roll forming machine ------------------------ 1 Unit
  • Hydraulic cutting device --------------------------- 1 Unit
  • Hydraulic Station ------------------------------------ 1 Unit
  • PLC computer control ----------------------------- 1 Unit
  • Output table ------------------------------------------ 1 Unit
  • Elbow machine --------------------------------------- 1 Unit

Working Flow

Decoiler--> Coil sheet guiding and feeding --> Roll forming machine with safty guard--> Tighten Device -> Cut to

length --> Out-put Table --> Curving machine

Applications

Rainwater downpipe, downspout, rainspout, water pipe, drainpipe

3" * 3" Squared Rainwater Downpipe Roll Forming Machine For Water Pipe, Rain Gutter

Our Advantage

  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience

Machine Pictures

3" * 3" Squared Rainwater Downpipe Roll Forming Machine For Water Pipe, Rain Gutter
